Rivet Counter HO Scale EMD GP30u, Santa Fe/Nose Headlight DCC & Sound

SKU's:

SXT40917 Cab #2747

SXT40919 Cab #2753

SXT40921 Cab #2765

SXT40925 Cab #2772

• New paint scheme
• Era: Late 80s to Mid-90s
• Series ATSF 2746 to 2785 (rebuilt between 1982-1984)
  • ATSF 2753 and 2772
    • EOT antenna stand on left side of cab roof
  • ATSF 2747
    • EOT antenna stand on right side of cab roof
  • ATSF 2765
    • EOT antenna stand on right side of cab roof
    • Mounting flanges from removed inertial air intake hoods remaining on long hood roof behind cab
• All road numbers feature:
  • Front ATSF-style relocated LED-illuminated headlight with lenses in low short hood; blanked number board light mount
  • GP30 cab with increased length on left (fireman’s) side, cab heater vents deleted, and flat center windshield section
• Fully-assembled
• Multiple road numbers
• LED-illuminated ground lights on both sides of locomotive*
• LED-illuminated “hemisphere” walkway lights on hood ends, and at end of raised walkway duct*
• Blanked front and rear class lights with round plate
• LED-illuminated, printed and backlit cab number boards, and blanked long hood end number boards
• Vapor Corp. cab roof HVAC
• Front and rear multiple unit (MU) hose catch bars
• 3-hose multiple unit (MU) hose clusters with silver gladhands
• Semi-scale coupler buffer equipped with durable metal semi-scale Type E knuckle couplers
• Front and rear straight uncoupling levers with loop handles; two inner and two outer mounting brackets
• Modified pilot faces with uncoupling lever loop notches
• Deck-mounted multiple unit (MU) receptacle
• Dummy multiple unit (MU) receptacles with cable mounted to pilot face
• Handrail set with center gangway chains
• Front and rear standard drop steps
• Scale sectioned treadplate detail with EMD early “X” style pattern
• 81” GP30 low short hood with ratchet handbrake, chain guard, and square sand fill
• Hinged battery box doors with early hinges and narrow louvers
• Early cab sub-base doors with early hinges
• Detailed cab interior with separate floor, rear wall, seats, and standard AAR control stand
• Rectangular vent on left side of cab
• Sliding cab side windows
• Tall wind wings mounted fore of cab windows, left side, and small mirror on right side
• Standard EMD sunshades with long sunshade tracks
• Lost-wax brass cast Nathan AirChime K3LA horn mounted to right side cab roof eave.
• Large Sinclair Excalibur “ice skate” antenna (communications) mounted on a stand centered on the cab roof
• Accurate hood door and long hood detail
• Late single-panel inertial compartment with retrofitted latched and hinged access doors
• Wire inertial air intake grills
• Tall turbo exhaust stack
• Standard-range dynamic brakes with 48” fan
• Late See-through dynamic brake intake grills with horizontal wires through vertical vanes
• 7-horizontal rib radiator intake grills
• See-through front and rear 48” radiator fan housings with 8-blade fans; 36” pan-top center radiator fan
• Curved radiator fan grab iron
• Square sand fill hatch on top of long hood end
• Rear LED-illuminated horizontal headlight with lenses
• Underbody frame rail with separate plumbing
• Detailed Blomberg-B trucks with Hyatt bearing housings; elliptical springs; end transom detail; separate sanding lines and brackets; deleted outer brake shoes; and separate swing hanger detail
• Dimensionally accurate truck centers
• Aeroquip speed recorder on #2 axle, left side.
• Spare knuckle holders mounted to truck sideframes
• Frame-mounted bronze bell
• Prime air filter (can style)
• 2,600-gallon fuel tank sill skirt removed and relocated vertical gauges; round gauges in fuel tank sides; fuel fillers exposed
• Factory-applied wire grab irons, photoetched lift rings, windshield wipers, trainline hoses with silver gladhands, air tanks, sand hatch covers and more
• Motor with 5-pole skew wound armature
• Dual flywheels
• All-wheel drive
• All-wheel electrical pick-up
• Directional LED-illuminated headlights
• Printing and lettering legible even under magnification
• Operates on Code 70, 83, and 100 rail
• Packaging safely stores model
• Minimum radius: 18”
• Recommended radius: 22”
